Customized 5 Watt GSM Network Booster 2G 900MHz Cellular Apmifier

  • 1
  • 2

Payment Terms : T/T,Western Union,Paypal,Bank transfering

Material : Zinc Alloy ,Plastic

Booster Warranty : 3 years

Brand Name : ATNJ

Model Number : AT-37-G

Certification : CE,ROHS，CCC，TUV,BV， ISO

Place of Origin : China

MOQ : 5Pcs

Price : USD+1100--1200+kit

Supply Ability : 1000+unit+per day.

Delivery Time : 3-5 work days

Packaging Details : Standard neutral packing

Products Type : repeater ac 12000, repeaters gsm

Booster Bandwidth : Wide Range

Frequency Range : 890-915MHz / 935-960MHz

Support network : 2G 3G, Voice

Contact Now

Customized 5 Watt GSM Network Booster 2G 900MHz Cellular Amplifier

5 Watt Customized GSM mobile signal booster 2G 900MHz cellular amplifier

Frequency Combinations
  • Band 800: Uplink:824-849 MHz Downlink: 869-894 MHz (B20 800 available)
  • Band 900: Uplink:880-915 MHz Downlink:925-960 MHz
  • Band 1800: Uplink:1710-1785 MHz Downlink:1805-1880 MHz
  • Band 1900: Uplink:1850-1910 MHz Downlink:1930-1990 MHz
  • Band 2100: Uplink:1920-1980 MHz Downlink:2110-2170 MHz
  • Band 2300: Uplink:2305-2315 MHz Downlink:2350-2360 MHz
  • Band 2600: Uplink:2500-2570 MHz Downlink:2620-2690 MHz
Technical Specifications
  • Band Options: Single Band, Dual Band, Tri Band, Four Band, Free combinations
  • Output Power: 5W/10W/20W
  • Power Supply: AC adapter
  • Size: 308×219×135mm
  • Weight: 7.0kg
Single Band Repeater Specifications (Model AT-37-G)
Frequency Range Uplink: 890-915MHz Downlink: 935-960MHz
Working System Band8 GSM 900MHz
Gain 85dB
Device Output Power 37dBm
Bandwidth Wide Range
Ripple in Band ≤4dB
Noise Figure @ Max.Gain ≤6dB
V.S.W.R ≤2dB
MTBF >50000 Hours
Power Supply AC110V-220V; DC+24V5A
Power Consumption <20W
Impedance Matching 50ohm
RF Connector N/F
Cooling Heatsink Convection Cooling
Dimension 170×130×26(mm)
Net Weight 0.35KG
Installation Type Wall Installation or Desk
Environment Conditions IP55X
Origin Shenzhen
Operating Temperature -10°C to 55°C

For detailed product specifications, click here to download.

Key Selling Points
  • One device connects with several antennas to cover large area
  • Wide Coverage Up To 3000 ㎡
  • Max Output Power: 33dBm Support 2 to 5 Bands
  • Industrial Design IP65 level waterproof
  • Full Intelligent LCD Guide
  • Three years warranty, worry-free after-sales
Product Features
  • High output 5W, stable fast speed signal, perfect for large area or high building signal improvement
  • Easy installation process
  • Die cast aluminum alloy outer shell for efficient heat dissipation, waterproof, dust proof, IP55 level
  • Energy saving: automatically enters dormancy status when no phone signal detected; activates in 0.2 seconds when signal present
  • Upgrade intelligent WTR chip integrated circuit, reduced attenuation, higher load capacity, faster speed
  • Free settings depending on environment, maximum coverage up to 6000sqm
Product Images
Customized 5 Watt GSM Network Booster 2G 900MHz Cellular Apmifier Customized 5 Watt GSM Network Booster 2G 900MHz Cellular Apmifier Customized 5 Watt GSM Network Booster 2G 900MHz Cellular Apmifier Customized 5 Watt GSM Network Booster 2G 900MHz Cellular Apmifier

We are manufacturer and have our own factory.

Frequently Asked Questions
Q1: I am in Romania and which band/frequency should I choose?
Customized 5 Watt GSM Network Booster 2G 900MHz Cellular Apmifier
Typically, frequencies used by mobile operators in Romania are 900/1800MHz for 2G, 900/2100MHz for 3G, and 800/1800/2100/2600MHz for 4G and part of 5G. Contact us to confirm the suitable model for your location.
Q2: Do you have CE or any other certification?
Yes, we have CE, ROHS, and FCC certification, etc.
Q3: Can you give me a discount?
Please discuss with our sales team.
Q4: How about gain and output power of your device?
Different models have different gain and output power specifications. For more details, please contact us.
Q5: How long is warranty period?
The warranty is 12 months, and we offer 7×24 technical support.
Q6: How many square meters can be covered?
Coverage area varies by model. Different models cover different square meters.
Q7: Can I use your device in suburbs or remote areas?
Yes, as long as you can find a good signal source, our signal booster can help solve signal problems in remote areas.
